XK-S Steel Workstation Cranes

| Strong, robust and flexible lifting

Konecranes XK-S workstation cranes meet the demanding requirements of workplaces and production lines with a lifting capacity of up to 2,000 kg. For precise and repetitive actions, especially on heavy loads, workers need a reliable, easy-to-use crane that is quick to install, to follow tight production schedules, save costs and reduce downtime.

This crane is a hard, durable lifting tool, with a long lifetime and reduced maintenance costs due to dust and dirt protection. Its strong, robust and enclosed steel profile allows for long spans and suspension distances. Offering exceptional utility and adaptability, it is available ceiling-mounted or freestanding, single or double girder, or even on a monorail

Product Features

The XK-S workstation crane has the following product features:

•    Strong and robust steel runway
•    Modular system with multiple profile sizes
•    Different system configurations, including:

  • monorail

  • single and double girder bridges with articulated or rigid movement

  • freestanding structures

  • telescopic cranes

  • installations for manipulator handling

•    Manual or motorized trolleys and bridges
•    Smooth-running trolleys with low rolling resistance
•    Service hatch for easy trolley inspection and maintenance
•    Energy supply via festoon or integrated conductor lines
•    Low headroom available
•    Long suspension distances and span lengths
•    Dust and dirt protection
•    Can be combined with aluminum runways and bridges

Technical specifications

The XK-S workstation crane has the following standard technical specifications:

  • Intended for indoor use

  • Design follows EC machinery directives

  • Ambient temperature range limits -10°C to +40°C

  • Corrosion category at least C2-M (acc. to DIN EN ISO 12944)

  • Crane control via pendant or radio

  • Up to 6 bridges on one runway

Performance data for single-girder cranes:

PROFILE SIZE

100

I

II-L

II

II-H

A12

A16

A18

A22

LOAD CAPACITY [KG]

GIRDER LENGTH (M)

80

3

6

8

8



5

8

8

8

125

3

5

8

8

14

4

6

8

8

250



3

7

8

13

2

4

7

8

500



2

4

7

11

2

3

4

6

1000





2

4

7





3

4

1600









6







3

2000









5







3



Performance data double-girder cranes:

PROFILE SIZE

100

I

II-L

II

II-H

A12

A16

A18

A22

LOAD CAPACITY [KG]

GIRDER LENGTH (M)

XK-S XK-A



5

9

10

12

14

7

8

8

8

250



6

10

12

14

5

8

8

8

500



4

7

11

14

3

4

8

8

1000





5

7

12





5

6

1600







5

9







5

2000







4

7







4



Also available with specifications outside this standard offering on a case-by-case basis.

Benefits

•    Easily combined with electric chain hoists, pneumatic lifting devices or manual hoists for a versatile workstation lifting system
•    Ideal for heavy-duty operations
•    Adaptable for all kinds of workstation applications
•    Long suspension distances and travel over long span lengths
•    Easy installation, modification and extension
•    Maximized working area below the crane
•    Long lifetime and reduced maintenance costs
•    Fast installation with standardized profiles and bolt-on connections
•    Comprehensive service solutions help increase efficiency, safety and performance
